AUDISON

Audison AF C4.10 bit

$1,149.99 USD $1,310.00 USD
Snap Logo Lease for as low as $/week Apply Now

DSP Amplifier | 600 W | 10 CH DSP + 4 x 150 W @ 2 ohm | D-class Fully Bridgeable

AF C4.10 bit boasts four high-fidelity amplified channels 90W x 4 @4Ω*, 150W x 4 @2Ω*, with the audiophile sound of the latest generation Audison D-Class technology. Higher switching frequencies, steeper filtering, and higher-tolerance components deliver sound above and beyond the expectation of Class D – in an amazingly compact package! This is combined with native DSP working at 24 bit/96 kHz, extending the audio band up to 40 kHz and earning the coveted High-Resolution certification. Bridging channel pairs results in 300 x 2 @4Ω, guaranteeing flexible and powerful performance. Support for the Audison B-Con’s Absolute Volume function guarantees maximum bit depth, even with wireless connections!*Output Continuous Power (RMS) @14.4 VDC, 1% THD, all channels driven.

FEATURES

  • Improved audio performance and power thanks to the latest generation of ADT (Audison D-Class) technology
  • Unbeatable power/volume ratio up to 0.68 W RMS/cm³ reaching 81% of efficiency
  • Next-generation bit Drive software platform
  • Hi-Res compatibility performance, with an extended audio band up to 40 kHz, made possible by and DSP working operation at 24 bit/96 kHz
  • Maximum versatility thanks to the possibility of using the bridging option for each pair of power outputs
  • Up to 10 output channels (4 amplified, 6 native pre-out outputs, 4 optional pre-outs) controlled by the DSP to expand the system with other amplifiers
  • 8 high/low-level inputs (and an optical Toslink digital input) support total connectivity even with the most complex OEM systems
  • Extension card slot (additional 4 analog or 1 digital inputs)
  • Electrical signal analysis for each input channel ensures proper integration and correction
  • Acoustic analysis (with your USB microphone) integrates the response graph into the equalizer display. This ensures efficient tuning and great sound!
  • Advanced signal routing options allow the technician to go beyond the predefined system definitions in the Configuration Wizard

AMPLIFIER TECH DATA

Channels 4
Class D-Class
Power supply voltage / fuse 11 ÷ 15 VDC / 1 x 30A
Operating power supply voltage 6.5 ÷ 17.5 VDC
Idling current 1 A
Standby Current Draw 1 mA
Consumption @ 14.4 VDC, 2Ω, Max Musical Power 29 A
Remote IN 4 ÷15 VDC (1 mA)
Remote OUT 6.5 ÷15 VDC (150 mA)
ART - Automatic Remote Turn on/ off from OUTPUT BTL speakers 1.5 VDC
AST - Automatic Signal Turn on/off (Selectable) 1.5 VDC
Efficiency Rated Power 81%



AMPLIFIER STAGE

Distortion - THD @ 1 kHz, 4Ω, 70% Rated Power 0.03%
Bandwidth @ -1.5 dB 10 Hz ÷ 42 kHz
Damping factor @ 1 kHz, 4Ω, 2 VRMS 95
S/N ratio (A weighted @ 1 V Input) Master Input 98 dBA
S/N ratio (A weighted @ 1 V Input) Optical Input 105
Total Power RMS 600 W
Minimum load impedance 2Ω
Output Continuous Power (RMS) @14.4 VDC, 1% THD 4 Ch @ 4Ω: 90 W x 4

4 Ch @ 2Ω: 150 W x 4

2 Ch (Bridge 1/2; 3/4) @ 4Ω: 300 W x 2
Adjustable Crossover Yes
