KICKER
KICKER 6"x8" CS Series CSS68 COMPONENT
CS Series CSS68
The CS 6x8-Inch Component Speakers are the perfect factory upgrade when you have a separate woofer and tweeter.
CS components include separate Titanium tweeters and two-way crossovers with tweeter level control, to let you customize your sound for the best sonic quality.
These CS speakers work best with 75 watts of recommended power. See below for more details.
Specifications
| Woofer Size | in [mm] |
| 6x8 [160x200] |
| Tweeter Size | in [mm] |
| 3/4 [20] |
| Dome Material |
| Titanium |
| Peak Power | [watts] |
| 225 |
| Continuous Power | [watts RMS] |
| 75 |
| Effective Frequency Range | Hz |
| 40-21k |
| Woofer Mounting Hole Diameter | in [mm] |
| 5 x 7 3/16 [126x182] |
| Woofer Bottom Mount Depth | in [mm] |
| 2 3/16 [56] |
| Flush Mounting Tweeter Hole Diameter | in [mm] |
| 1 9/16 [40] |
| Flush Mount Tweeter Depth | in [mm] |
| 9/16 [14.5] |
| High Pass | dB, at Frequency | Hz |
| 12, 4000 |
| Low Pass | dB, at Frequency | Hz |
| 12, 4000 |
| High Frequency Output Attenuation | dB |
| 0, 3, & 6 |
| Bolt-Thru Grilles |
| No |
