NAD Masters M10 V2 BluOS Streaming Amplifier
Like the original M10, the M10 V2 exemplifies the “Just Add Speakers” revolution in hi-fi. But it takes that revolution a giant step further. Along with audiophile-grade speaker terminals, it has two independent subwoofer jacks, whose output settings are adjustable from the BluOS app. The M10 V2 adds Dolby Digital surround-sound decoding. Home-theatre fans can configure a pair of BluOS surround-enabled wireless speakers or amplifiers to play the surround channels, while the main speakers handle the front channels, so that the M10 V2 serves as the hub of a 4.1- or 4.2-channel Dolby Digital surround setup. The M10 V2 transmits the rear channels wirelessly, with very low latency, so you don’t have to run wires around your room to connect the surround speakers.
Features & Details
- BluOS Streaming Amplifier
- 4.0, 4.1, and 4.2 channel surround options by adding BluOS Enabled players like the PULSE FLEX (wireless) and PULSE SUB (wired) by Bluesound
- Hybrid Digital nCore Amplifier with updated gain algorithms
- Continuous Power: 100W into 8/4 Ohms
- Dynamic Power: 160W into 8 Ohms 300W into 4 Ohms
- 32-bit/384kHz ESS Sabre DAC
- Dirac Live Room Correction
- 7″ IPS colour LCD touchscreen
- BluOS multi-room compatible
- AirPlay 2 integration, with support for Siri Voice Assistant
- Amazon Alexa voice control skills
- Roon Ready
- Spotify Connect and Tidal Connect
- Gigabit Ethernet
- Two-way Qualcomm aptX HD Bluetooth
- NFC Bluetooth pairing for compatible smart devices
- HDMI eARC,USB Type A inputs
- Stereo line analogue and coaxial/optical digital inputs
- Preamp output, two independent subwoofer outputs with updated gain algorithms
- IR Input, 12V Trigger Out
- Apps for iOS, Android, macOS, Windows, Crestron, Control4, RTI, URC, Elan, Lutron
- Wide variety of premium music services supported in BluOS app, including Amazon, Spotify, Tidal, TuneIn, Napster, Deezer, Qobuz and many others
- Support for all major lossless and lossy formats, including WAV, FLAC, AIFF, ALAC, AAC, MP3, Ogg Vorbis, and others
- MQA decoding and rendering
- Infrared remote control handset included
*The M10 V2 includes a license for Dirac Live with the option for advanced users to upgrade to a Dirac Live Full Frequency version.
AMPLIFIER SECTION
|
Continuous output power into 8 ohms and 4 ohms |
>100W (ref. 20 Hz-20 kHz at rated THD, both channels driven) |
|
THD (20 Hz – 20 kHz) |
<0.03 % (250 mW to 100 W, 8 ohms and 4 ohms) |
|
Signal-to-Noise Ratio |
>85.1 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms) |
|
Clipping power |
>130 W (at 1 kHz 8 ohms 0.1 % THD) |
|
IHF dynamic power |
8 ohms: 160 W |
|
Damping factor |
>190 (ref. 8 ohms, 20Hz to 6.5kHz) |
|
Frequency response |
±0.6 dB (20 Hz – 20 kHz) |
|
Tone controls |
Treble: ±6.0 dB at 20 kHz |
|
Channel separation |
>83 dB (1 kHz) |
|
Input sensitivity (for 100 W in 8 ohms) |
Line In: 456 mV |
|
Standby power |
<0.5W |
DAC SECTION |
|
|
ESS Sabre 9028 DAC |
|
|
Supported audio file formats |
MP3, AAC, WMA, OGG, WMA-L, ALAC, OPUS |
|
Hi-Resolution audio formats |
MQA, FLAC, WAV, AIFF, Supports converted DSD playback via the BluOS desktop app (only) |
|
Sampling rate |
up to 32 bit/192 kHz PCM |
|
Bit depths |
16 – 24 |
BluOS SECTION |
|
|
Supported operating systems |
Plays music from network shares on the following desktop operating systems: Microsoft Windows XP, 2000, Vista, 7, 8 to current Windows Operating Systems and Mac OS X versions |
|
User interface mobile operating system BluOS |
BluOS – Free Android and iOS App available online at Google Play and Apple App store |
|
Supported cloud services* |
Amazon Alexa, Amazon Music, Spotify, TIDAL, Deezer, Qobuz, HDTracks, HighResAudio, Murfie, JUKE, Napster, Slacker Radio, KKBox, Bugs |
|
Free internet radio* |
TuneIn Radio, iHeartRadio, Calm Radio, Radio Paradise |
|
Bluetooth quality |
Bluetooth aptX HD built-in |
|
Bluetooth connectivity |
Two-Way (Receive and Headphone modes) |
|
Network connectivity |
Gigabit Ethernet RJ45, Wi-Fi 5 |
|
Gross dimensions (W x H x D)** |
215 x 100 x 260 mm |
|
Shipping weight |
5 kg (11 lbs) |
