ROCKFORD FOSGATE Punch 300 Watt 2-Channel Amplifier

The Punch P300X2 is a 2-channel stereo amplifier capable of producing 150 Watts into each channel at 2-Ohms. The P300X2 amplifier is great with full-range or component systems and can be bridged for use with smaller subwoofers.

The P300X2 is a solid choice if you're looking to drive a pair of coaxial speakers, component speakers, or a single subwoofer. The amplifier can also be run in stereo/mono mode simultaneously when using passive crossovers (not supplied) on all speakers. With proven PUNCH technology, the P300X2 delivers real Rockford Fosgate power from a small design and is flexible to accommodate any moderately sized system.

• High level input capable with Auto Turn-On circuit
• RCA pass-thru outputs
• Features C.L.E.A.N. Set-up
• Optional remote Punch Level Control (PLC2) ready (w/ input clip indicator)
• 12dB/octave Butterworth crossover
• On-board Punch EQ with +18dB boost @ 45Hz
• Muted turn on
• Stealth top mounted control panel
• Cast aluminum heatsink
• Short circuit protection
• Over current protection
• 1 Year Warranty

CEA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines mean your amplifier's ...

Learn more

x

CEA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines mean your amplifier's output power ratings are REAL POWER numbers, not inflated marketing ratings.

TRANS•ana

Trans•ana is a Class A/B topology that simplifies the signal path of the amplifier allowing the ...

Learn more

x

TRANS•ana

Trans•ana is a Class A/B topology that simplifies the signal path of the amplifier allowing the signal to travel through the amplifier at a lower voltage. The result is greater reliability and exceptional sound quality.

CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 ...

Learn more

x

CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 EC).

Balanced Differential Inputs

Differential inputs eliminate noise picked up by signal cables.

Learn more

x

Balanced Differential Inputs

Differential inputs eliminate noise picked up by signal cables.

DTM

Dynamic Thermal Management evenly distributes excess heat across entire amplifier heatsink.

Learn more

x

DTM

Dynamic Thermal Management evenly distributes excess heat across entire amplifier heatsink.

DSM

DSM utilize 1% tight-tolerances improving efficiency of the circuit, decreases cross-talk from other discrete components and ...

Learn more

x

DSM

DSM utilize 1% tight-tolerances improving efficiency of the circuit, decreases cross-talk from other discrete components and lowers operating temperature.

MEHSA³

MEHSA³ reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.

Learn more

x

MEHSA³

MEHSA³ reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.

NOMAD

NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and ...

Learn more

x

NOMAD

NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and dangerously low speaker impedances.

Engineered In The USA

These Avatars are a personal signature from the Rockford Fosgate team member(s) who designed and engineered ...

Learn more

x

Engineered In The USA

These Avatars are a personal signature from the Rockford Fosgate team member(s) who designed and engineered this fanatic product. This statement illustrates our commitment to being Designed and Engineered in the U.S.A.

C.L.E.A.N. Set-Up

Patented circuit with in/out clip LEDs to help match a source to amp and optimize output.

Learn more

CEA-2006 Compliant

CEA-2006 Power Rating
100W x 2 @ 4Ω
≤1.0% THD+N

Number of Channels

2

Total Power
(Sum of Rated Power)

300 Watts

Rated Power
(RMS Continuous Power)

100 Watts x 2 @ 4-Ohm
150 Watts x 2 @ 2-Ohm
300 Watts x 1 @ 4-Ohm Bridged

Dynamic Power
(PVC/PowerCube®)

120 Watts x 2 @ 4-Ohms 0° Res
203 Watts x 2 @ 2-Ohms 0° Res

Bridgeable

Yes

Frequency Response

20Hz-20kHz

Input Sensitivity

150 mV - 12 V

Circuit Topology Class

Class A/B

Efficiency (average)

69% @ 4-Ohm

Total Harmonic Distortion (THD+Noise)

4-Ohm: <1.0%
2-Ohm: <1.0%

Signal Input

Hi/Low Level: 1 RCA Pair

Signal Output

Low Level: 1 RCA Pair

Tone Controls

0dB to +14dB @ 12.5kHz
0dB to +18dB @ 45Hz

Crossover Controls

High-Pass: 50Hz - 250Hz @ 12dB/Octave Butterworth
Low-Pass: 50Hz - 250Hz @ 12dB/Octave Butterworth
All-Pass: Yes

Remote Controls

Optional Punch Level Control (PLC2) Ready

Visual Indicators

Power/Protect/Thermal LED
Input Clip LED³
Output Clip LED^1,2,3

LED Color Legend:
¹BLUE: <0.5% THD
²VIOLET: 1% THD
³RED: 10%+ THD

Power Wire Gauge

8 AWG to 4 AWG

Power Input Connector

Captive C-Clamp

Speaker Wire Gauge

8 AWG to 18 AWG

Speaker Output Connector

Captive C-Clamp

Cooling

Convection

Heatsink

Operating Voltage

9 - 16 VDC

Recommended Fuse
(not included)

50 A

Average Current Draw (13.8V Music)

23 A

Max. Current Draw (13.8V Sinewave)

45 A

Suggested Alternator

75 A

Dimensional Diagram

Dimensions (H x W x D)

2.38 x 7.76 x 9.86 (in)
6.05 x 19.71 x 25.04 (cm)

Shipping Weight

9.5 Lbs. (4.3 Kg.)
